S41-2
SafeWay’s S20 Series is a general purpose, double shut-off, fluid transfer quick coupling available with either a rugged ball valve or leak-free, high flow poppet valve. The S20 Series is used primarily on agricultural equipment and is recognized as an economical and reliable quick coupling. This series is original equipment on snow plows, garden tractors, full size tractors, front-end loaders, skid-steer loaders, earth moving, and mining equipment.
Product Details
Additional information
| Coupler Size (Inch) | 0.250000 |
|---|---|
| Coupler Size (mm) | 6.3 |
| Diameter (in) - G | 0.860 |
| Hex (in) - H | 0.750 |
| Interchangeable Series | 4000 (Parker Pioneer Series), 60 (Snap-tite Series), FD42 (Aeroquip Series) |
| Lock Style | Ball |
| Material | Steel |
| Rated Flow (GPM) | 3.0 |
| Rated Flow (L/Min) | 12 |
| Series | S20 |
| Thread | 1/4 Female Pipe |
| Tip Length (in) - F | 1.320 |
| Valve Type | Ball (Metal Seal) |
| Maximum Operating Pressure (bar) | 207 |
| Maximum Operating Pressure (psi) | 3000 |
| Description | Tip Half |
